industrial 3D model Pressure Equipment AOI LCD Display Industry
$150
This is industrial 3D model Pressure Equipment AOI LCD Display Industry. In the field of liquid crystal panel technology, the AOI pressure device for liquid crystal panel consists of a body, the first end of the body is provided with an inlet, and the second end of the body is provided with a discharge end. The feed end is connected to the discharge end of the OLB processing unit. , the body is equipped with a pedestal to receive, position and move the glass, a glass support beam to ensure the tilt of the glass, and a mechanical arm to transport the glass from the discharge end to the next process. The whole machine adopts solidworks design, which is completely similar to Korea’s AOI pressure equipment, and can be used as a design reference for related equipment! ! !
Industry use: Equipment
3D model Design software: SolidWorks
3D model Version/edit:2018 [editable, with parameters]
3D model File format:Sldprt Sldasm SLDDRW
This is industrial 3D model Pressure Equipment AOI LCD Display Industry. In the field of liquid crystal panel technology, the AOI pressure device for liquid crystal panel consists of a body, the first end of the body is provided with an inlet, and the second end of the body is provided with a discharge end. The feed end is connected to the discharge end of the OLB processing unit. , the body is equipped with a pedestal to receive, position and move the glass, a glass support beam to ensure the tilt of the glass, and a mechanical arm to transport the glass from the discharge end to the next process. The whole machine adopts solidworks design, which is completely similar to Korea’s AOI pressure equipment, and can be used as a design reference for related equipment! ! !
Industry use: Equipment
3D model Design software: SolidWorks
3D model Version/edit:2018 [editable, with parameters]
3D model File format:Sldprt Sldasm SLDDRW
