industrial 3D model Robot position welding equipment


    This is industrial 3D model Robot position welding equipment Robot position welding equipment 1. Lifting of the welding platform is done by the motor on the T-shaped screw drive column. It has a self-locking function to ensure that the self-locking pin will not be dropped during power failure. 2. The welding platform rotation is controlled by the motor-driven rotary holder. When the double columns are working, the motor of the right column is inactive and disconnected from the rotating support. When two columns are used alone, the right column gear and the Rotation Support Unit engage to drive the turntable. 3. The right column can be rotated with manual assistance. After the rotation is complete, the bolts are tightened and fixed. It can be used as a separate welding rotary positioner. Industry use: Equipment Design software: SolidWorks Version/edit:2014 File format: Sldprt Sldasm
