industrial 3D model Toilet paper roll cutter


    industrial 3D model Automatic roll paper cutting machine with knife 1. Description (1) The equipment is easy to operate, low noise, stable operation and high production efficiency (2) The whole machine is controlled by PLC program, frequency conversion speed control and touch screen operation (Siemens brand) (3) Driven by servo motor (4) Feed control servo motor to provide precise cutting length (5) Single channel conveyor (6) Equipped with advanced photoelectric detection system (7) The device stops automatically when there is no material (8) Automatic edge material cleaning device (9) Low knife consumption, low power consumption (10) Cutting speed and length can be set via touch screen, advance and cut more smoothly and continuously (11) Smooth and precise slitting (12) Automatic grinding For man-machine controlled cutting system. 2. Machine equipment specifications Dimensions L3750mm*W2200mm*H1850mm L4560mm*W2200mm*H1850mm Machine weight 1200kg 1300kg Channel parameters L2200mmФ65-125mm H1900mm L4560mmФ65-125mm H1900mm Air source pressure 0.5mpa~0.8mpa Power supply 3 phase 4 wire, 380V, 50HZ, 4.5KW (other voltage can be customized) production speed 75-105 cuts/min cutting length 90mm ~ 180mm error ± 1mm Specifications of belt knife 3880mm × 52mm × 0.6mm PLC feeding control, servo motor control Knife sharpening control, automatic sharpening knife feeder, man-machine interface control of sharpening angle Industry use:Equipment
    3D model Design software: SolidWorks
    3D model Version/edit:2017
    3D model File format: Sldprt Sldasm
